Product details
Specification
- 100% Made in Britain
- Certified to EN16630, (legacy standards, BSI PAS888 - safety compliant for ALL ages, users and non-users & DIN79000 - safety compliant for users, aged 14+). All TGO outdoor gym equipment is free from exposed end stops, entrapments and sharp edges
ALWAYS ASK FOR EN16630 FOR OUTDOOR GYMS
- Great instructional signage- workout QR code videos, start and finish diagrams.
- Weatherproof
- Resistance-based equipment - no electricity required
- Low maintenance
- Designs include key elements of Inclusive Fitness Initiative guidelines
- TGO plant a tree in the NHS Forest for every piece of equipment sold
- Anti vandal fixings
- Available in all major RAL colours
- Stop mechanisms concealed
- Paint UV stabilised
- Welds certified to EN15015614
- Powder coated finish
- Separate ground anchor for future upgrades
Production details
Manufacturer Standard: EN16630 (legacy standards - PAS888, Din79000)
Framework: Mild Steel Grade S275 (min 3mm thick)
Finish: High quality gloss finish polyester powder coat paint
Signage: High quality reverse printed PETG (Integrated coming soon)
Backs: Enhanced Polyphenylene Ether (PPE) Resin
Enhanced corrosion protection
An enhanced corrosion protection is available on request for this product. Hot dip galvanising is the process TGO use to add a protective coating to the body of our products on our equipment in coastal areas, which have higher air salinity or in harsh urban and industrial atmospheres with higher sulphur dioxide pollution*.
The upgrade includes:
- Upgrading to hot dip galvanising
- Fixings are upgraded from A2 to A4 stainless steel
*An upgrade to galvanised steel will be necessary for the warranty in these environments.
Installation
This product is installed onto three generic TGO Large Ground Anchors. Please see the ‘TGOGC Installation & Assembly Guidelines’ for guidance on installing this anchor. Leg Press spacing is based on 5ft (1524mm) to 6ft (1829mm) individuals.
Safety
This product requires 1.5m of clear space around the equipment (green outline).
- Fall height: 0.6m
- Clear Space: 35.4m²
There is no safer surface requirement and therefore TGO only recommend a minimal surface area (grey outline).
Parts list
|
No
|
Part
|
Dimensions
|
Weight
|
Qty
|
|
1
|
Leg Press Track Assembly**
|
L1207, W561, H1021
|
95kg
|
1
|
|
2
|
Leg Press Platen****
|
L168, W466, H401
|
11.3kg
|
1
|
|
3
|
Lat Pull Down / Shoulder Press
|
L1993, W988, H1943
|
160kg
|
1
|
|
4
|
Cross Trainer***
|
L1182, W523, H1610
|
108kg
|
1
|
|
5
|
Large Ground Anchor*
|
L777, W489, H344
|
23kg
|
3
|
* Substituted with 6x HILTI fixings for surface mounted option
** Based on the product in a rested position
*** Based on greatest value position
**** Including four (4) spreader plates
