• L2.2m x W1m x H2.2m
• Users: 2+
• Galvanized steel
• We can leave the bar unpainted for grip
• Powder coating – standard colour is TGO green or black, however there are a variety of colour options

1. 100% Made in Britain
2. Certified to EN16630, (legacy standards, BSI PAS888 - safety compliant for ALL ages, users and non-users & DIN79000 - safety compliant for users, aged 14+). All TGO outdoor gym equipment is free from exposed end stops, entrapments, sharp edges and crush points.
   ALWAYS ASK FOR EN16630 FOR OUTDOOR GYMS
3. Weatherproof
4. Strength-based equipment - no electricity required
5. Low maintenance
6. Designs include key elements of Inclusive Fitness Initiative guidelines
7. TGO plant a tree in the NHS Forest for every piece of equipment sold
8. Anti vandal fixings
9. Available in all major RAL colours
10. Paint UV stabilised
11. Welds certified to EN15015614
12. Powder coated finish

Manufacturer Standard: EN16630 (legacy standards - PAS888, Din79000)

Framework: Grade 316 stainless steel

Finish: High quality gloss finish polyester powder coat paint

Signage Plate: High quality reverse printed PETG

Guarantees: 25 years steel work, 2 years bearings, 5 years paint

An enhanced corrosion protection is available as standard for this product. Hot dip galvanising is the process TGO use to add a protective coating to the body of our products on our equipment in coastal areas, which have higher air salinity or in harsh urban and industrial atmospheres with higher sulphur dioxide pollution*.
The upgrade includes:

• Upgrading to hot dip galvanising
• Fixings are upgraded from A2 to A4 stainless steel

*An upgrade to galvanised steel will be necessary for the warranty in these environments.

Installation: This product is installed 700mm directly into the ground

Delivery: Comes in parts

This product requires 22m² of clear space around the equipment.

• Falling height: 1.2m
• Movement Space: L4.1m W5.3m
• Clear Space: 22m²

* Based on the greatest value position
